A 1990s band logo, press-separated in 8 hours.
No source art — just a phone photo of a worn tee. Re-illustrated from scratch and separated for a 4-station press with underbase and choke/spread for black garments.
Harbor Tees needed a 4-color screen print from a phone photo of a 30-year-old band tee — no vector source. VectorWiz re-illustrated the mark from scratch, separated it for a 4-station press with underbase and choke/spread, and delivered in 8 hours — well inside our 24-hour standard — with zero press reworks.
The job
Harbor Tees needed a 4-color screen print of a 1990s band logo, run on a 4-station press onto black garments. It was a Tier 4 screen-printing job with the artwork only living on the shirts themselves.
The problem with the source
There was no vector source — just a phone photo of a worn, 30-year-old printed tee. A snapshot of faded ink on fabric carries no clean edges to trace and no separable colors, so it can't be ripped to film as-is. The mark had to be rebuilt before it could ever reach a screen.
What we did
We re-illustrated the logo from scratch as true vector art, then separated it for the 4-station press. Because the print lands on black garments, the separation includes an underbase to make the colors read, plus choke and spread on the spot colors so the four screens trap correctly instead of leaving gaps or halos at the edges.
The production result
From the phone photo to delivery took 8 hours — well inside our 24-hour standard: a re-illustrated mark, fully press-separated into four spot colors with underbase and choke/spread dialed for black garments. It ran with zero press reworks — no re-burning screens, no registration chase.
Specialised for the way your shop runs
Production buyers don't need a generic vector — they need files that drop straight into the next step in the workflow.
Sign shops
Channel letters, banners, monument signs. Spot color, scaled to install dimensions, separated for routing.
Embroidery
Stitch-aware redraws, density-tuned fills, thread color pairings. Output paired with digitizing notes.
DXF / laser / CNC
Closed paths, single-stroke text, kerf compensation, tool-pathed for cut depth and material.
Vinyl cutters
Weed-friendly outlines, stroke-to-fill conversion, registration marks, and contour cuts you won't fight.
Engraving
Single-line stroke fonts, fill-vs-outline routing, depth-aware paths for rotary, laser, and burin work.
Signage fabricators
CNC-ready files for channel letters, dimensional letters, monument signs, ADA interior signage.
