Vehicle lettering and DOT numbers: cut-ready file setup.
Commercial vehicle lettering — company name, phone, and USDOT/MC numbers — is cut vinyl, so it needs clean closed vector paths with fonts outlined, built at the real applied size and separated by color. A plotter cuts the exact paths, so outlined vector is required; a raster logo is rebuilt as vector first. USDOT numbers must be legible per the carrier's requirement (commonly letters at least two inches tall in a contrasting color) — a spec you confirm and we build to.
Not every vehicle job is a full wrap. A huge share of the work is simple cut lettering — a company name on the doors, a phone number, the USDOT and MC numbers a commercial vehicle is required to carry. It is quick work when the file is right, and a weeding headache when it is not. Here is how to set it up.
Send the copy and sizes. Get cut-ready vinyl lettering back.
Name, phone, USDOT and MC numbers, and any logo — outlined, clean, contrast-separated, sized for the panel. In 24 hours.
Need something custom? Email hello@vectorwiz.com
It's cut vinyl, so it's vector
Cut lettering is produced on a plotter that drives its blade along vector paths. There is nothing to cut in a raster JPG or PNG, so the company name, numbers, and any small logo have to be clean closed vector with the fonts outlined. If the customer only has a raster logo, that piece is rebuilt as vector before it can be cut. Build the lettering at the real size it will apply at on the panel.
USDOT numbers: legible and contrasting
A commercial vehicle typically has to display the carrier's legal name and USDOT number so they are readily legible in daylight from a set distance — often set with letters at least two inches tall in a color that clearly contrasts with the vehicle. The precise requirement is the carrier's responsibility to confirm; the file's job is to render that copy cleanly at the size and contrast you specify.
Build it to weed and apply clean
The difference between a five-minute application and a fight is in the paths: outlined type (no hairline strokes), clean closed shapes, minimal nodes, and colors separated onto their own layers for a multi-color set. It is the same production-file discipline behind any clean sign job — the lettering just happens to go on a door.
Frequently asked questions
What file do I need for vehicle lettering and DOT numbers?
Clean closed vector paths — AI, EPS, PDF, or SVG — for the company name, phone, and USDOT/MC numbers, with fonts outlined so the plotter cuts the exact shapes. Cut vinyl lettering needs vector; a raster logo has to be rebuilt as vector first. Set it at the real applied size for the panel it goes on.
How big do USDOT numbers have to be?
Federal rules call for the carrier's legal name and USDOT number to be readily legible from a set distance in daylight — commonly set with letters at least two inches tall in a color that contrasts with the vehicle. The exact requirement is the carrier's to confirm; we build the lettering to the size and contrast you specify.
Does simple vehicle lettering need to be vector?
Yes, if it is cut vinyl — the plotter drives its blade from vector paths and cannot cut from a raster JPG. Outlined vector letters cut crisp and weed clean. If the customer's logo is raster, that part is rebuilt as vector before it can be cut.
Can you set up lettering that weeds and applies easily?
Yes. We outline the type, keep the paths clean and closed, size the lettering for the panel, and avoid hair-thin strokes that tear during weeding — cut-ready for your plotter and easy to mask and apply on the vehicle.
Can VectorWiz prep vehicle lettering and number sets?
Yes. Company name, phone, USDOT and MC numbers, and any small logo, built as clean cut-ready vector at the sizes you specify, contrast colors separated. Standard turnaround 24 hours, Rush 12; send the copy, sizes, and colors.
